Plastic Melt Flow Rate Index Tester , MFI Testing Device , Melting Point Apparatus , Melting Point Testing Machine

• Temperature range: 0 ℃ -400 ℃
• Double heating ring, double P100 temperature monitoring system (for HT-3682VM-7PT)
• Temperature display resolution: 0.1 ℃
• Temperature accuracy: ± 0.2 ℃ (HT-3682VM-7PT: ± 0.2 ℃)
• Temperature uniformity:

± 0.5 ℃ (HT-3682VM-7PT: ± 0.2 ℃)

• Volume timing resolution: 0.001S,Accuracy:0.01S
• Chinese GB / 3682-2018S standard die / half die diameter: Φ2.095 ± 0.005mm / Φ1.050mm ± 0.005mm; die length: 8.000 ± 0.025mm / Φ4mm ± 0.025mm(half die is optional)
• American ASTM D1238 standard die / half die diameter: Φ2.0955 ± 0.0051mm / Φ1.048mm ± 0.005mm; die length: 8.000 ± 0.025mm / Φ4mm ± 0.025mm
• Loading barrel diameter: Φ9.550 ± 0.007mm; length: 152 ± 0.100mm
• Piston rod head diameter: Φ9.475 ± 0.007mm, length: 6.350 ± 0.100mm
• Weight accuracy: ± 0.5%

• Japan Omron photoelectric rotary displacement measurement sensor
• Mold material: tungsten carbide
• Displacement measurement

accuracy: 0.01mm

• Test load: 2160g
• Countdown: 300s
• Melting index temperature: 230 ℃
• Volume method test range:

0.1-3000cm3/10min(displacement measurement)

• Measuring range of melt-blown material mass method: (0.1 ~ 2300) g/10min(displacement measurement)
• Measurement range of non-melt spray material mass method: (0.1 ~ 100)g/10min (cutting measurement)
• Output mode: Mini automatic printout
• Power supply voltage: AC220V ± 10% 50HZ or AC110 / 600HZ; choose different power supply voltage according to the country of use
• Weight: 60kg
